| Beta's profilation of this bike |
| Everyday, all around the world, there are many kids trying to make their first experiences on a dirt-track, learning how to face a curve or enjoying their first exciting high jumps, dreaming of being an Off-road Star.
But Beta Minicross is not only competition: beyond the will to win the most important thing is doing a sport to grow up with fun. Minicross is also a vehicle to improve safely the children’s concentration, balance and even consciousness and control of their own body.
To start the young riders aged 4/7, Beta designed a vehicle with 10” wheels, moved by a little 50cc engine, single-speed, enough brisk and prompt for the first trips in the dirt-tracks. The drum brakes guarantee quick and good stopping, while the readiness of the fork and rear shock nullify the ground asperities: MX10 is safety and fun!
|
| General moped information |
|---|
| Model: | Beta MINICROSS R 10 |
| Year: | 2007 |
| Category: | Minibike, cross |
| Rating: | 61.5 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 49.00 ccm (2.99 cubic inches) |
| Engine type: | Single cylinder, two-stroke |
| Compression: | 12.5:1 |
| Bore x stroke: | 39.5 x 40.0 mm (1.6 x 1.6 inches) |
| Fuel system: | Carburettor. Dell´Orto SHA 14 - 12L |
| Ignition: | Electronic Selettra |
| Lubrication system: | With fuel 1,5% (with synthetic oil) |
| Cooling system: | Air |
| Gearbox: | Automatic |
Transmission type,
final drive: | Chain |
| Clutch: | Wet automatic centrifugal type |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Steel tubing |
| Front suspension: | Mechanical fork with ø30 mm shaft |
| Front wheel travel: | 30 mm (1.2 inches) |
| Front tyre: | 2.50-10 |
| Rear tyre: | 2.50-10 |
| Front brakes: | Expanding brake (drum brake). Mechanical drive drum ø66 mm |
| Rear brakes: | Expanding brake (drum brake). Mechanical drive drum ø90 mm |
| Physical measures and capacities |
|---|
| Dry weight: | 37.5 kg (82.7 pounds) |
| Seat height: | 620 mm (24.4 inches) If adjustable, lowest setting. |
| Overall height: | 840 mm (33.1 inches) |
| Overall length: | 1,290 mm (50.8 inches) |
| Overall width: | 590 mm (23.2 inches) |
| Ground clearance: | 240 mm (9.4 inches) |
| Wheelbase: | 905 mm (35.6 inches) |
| Fuel capacity: | 2.00 litres (0.53 gallons) |
| Reserve fuel capacity: | 0.30 litres (0.08 gallons) |
| Other specifications |
|---|
| Color options: | Red |
