| Beta's profilation of this bike |
| Her catlike agility and grip fear no comparison and allow you to slip off the urban jungle with great immediacy and fun: the brand new M4 is capable to make things tricky for her rivals, whatever be their displacement. |
| General information |
|---|
| Model: | Beta M4 4T |
| Year: | 2010 |
| Category: | Super motard |
| Rating: | 3.0 Check out the detailed rating of off-road capabilities, engine performance, maintenance cost, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement: | 349.0 ccm (21.30 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Compression: | 9.5:1 |
| Bore x stroke: | 79.0 x 71.2 mm (3.1 x 2.8 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Carburettor. Mikuni BST 33 |
| Fuel control: | Single Overhead Cams (SOHC) |
| Lubrication system: | Forced with pump |
| Cooling system: | Air |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Wet multi-disc clutch |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Steel double cradle frame |
| Front suspension: | Hydraulic fork with ΓΈ46 mm shaft |
| Rear suspension: | Monoshock with adjustable spring preload |
| Front tyre: | 120/70-17 |
| Rear tyre: | 150/60-17 |
| Front brakes: | Single disc |
| Diameter: | 310 mm (12.2 inches) |
| Rear brakes: | Single disc |
| Diameter: | 220 mm (8.7 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 133.0 kg (293.2 pounds) |
| Seat height: | 870 mm (34.3 inches) If adjustable, lowest setting. |
| Overall height: | 1220 mm (48.0 inches) |
| Overall length: | 2160 mm (85.0 inches) |
| Ground clearance: | 305 mm (12.0 inches) |
| Wheelbase: | 1410 mm (55.5 inches) |
| Fuel capacity: | 10.50 litres (2.77 gallons) |
| Reserve fuel capacity: | 3.00 litres (0.79 gallons) |
| Other specifications |
|---|
| Color options: | Black |
| Starter: | Electric |
