Benelli's profilation of this bike |
Why should you stop when the road ends? We live on the same horizon, but we have different views.
That’s Benelli’s answer to the riders who go further !
|
General information |
---|
Model | Benelli Tre 1130 K |
Year | 2010 |
Category | Naked bike |
Rating | 4.2 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
Engine and transmission |
---|
Displacement | 1131.0 ccm (69.01 cubic inches) |
Engine type | In-line three, four-stroke |
Power | 123.4 HP (90.1 kW)) @ 9000 RPM |
Torque | 112.0 Nm (11.4 kgf-m or 82.6 ft.lbs) @ 5000 RPM |
Compression | 11.6:1 |
Valves per cylinder | 4 |
Fuel system | Injection |
Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
Lubrication system | Wet sump |
Cooling system | Liquid |
Gearbox | 6-speed |
Transmission type | Chain (final drive) |
Clutch | Wet multiplate |
Chassis, suspension, brakes and wheels |
---|
Rake (fork angle) | 25.0° |
Trail | 102 mm (4.0 inches) |
Front suspension | Upside down fork, 50 mm |
Front wheel travel | 150 mm (5.9 inches) |
Rear suspension | Steel trestle swingarm, progressive rear dumper with hydraulic extension and spring preload adjustments |
Rear wheel travel | 144 mm (5.7 inches) |
Front tire | 120/70-17 |
Rear tire | 180/55-17 |
Front brakes | Double disc. 4-piston cliper |
Diameter | 320 mm (12.6 inches) |
Rear brakes | Single disc. 2-piston caliper |
Diameter | 240 mm (9.4 inches) |
Physical measures and capacities |
---|
Dry weight | 215.0 kg (474.0 pounds) |
Weight incl. oil, gas, etc | 240.0 kg (529.1 pounds) |
Power/weight ratio | 0.5738 HP/kg |
Seat height | 840 mm (33.1 inches) If adjustable, lowest setting. |
Overall height | 1320 mm (52.0 inches) |
Overall length | 2183 mm (85.9 inches) |
Overall width | 850 mm (33.5 inches) |
Wheelbase | 1515 mm (59.6 inches) |
Fuel capacity | 22.00 litres (5.81 US gallons) |
Reserve fuel capacity | 4.00 litres (1.06 US gallons) |
Other specifications |
---|
Color options | Red, green, silver |
Starter | Electric |
Update specs | Report missing specs or required updates. |
Further information |
---|
Insurance costs |
|
Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
Ask questions | Join the 10 Benelli Tre 1130 K discussion group or the general Benelli discussion group. |
Related bikes | List related bikes for comparison of specs. |
|
Rating sample for this Benelli bike
|
Reliability for the 2010 Benelli Tre 1130 K:

(87.7 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
