| Arctic Cat's profilation of this bike |
| You need an ATV that cuts through the muddiest terrain like hot knife through butter, but won´t cut in on your budget. |
|
General information |
|
Model name
|
Arctic Cat MudPro 650 H1 |
|
Year of manufacture
|
2010 |
|
Type
|
ATV |
| Price as new | US$ 8599. MSRP depends on country, taxes, accessories, etc. |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
|
Engine and transmission |
|
Engine size
|
641.0 ccm (39.11 cubic inches) |
|
Type of engine
|
Single cylinder, four-stroke |
|
Bore x stroke
|
98.0 x 85.0 mm (3.9 x 3.3 inches) |
|
Valves per cylinder
|
4 |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Double A-Arm |
|
Front wheel travel
|
254 mm (10.0 inches) |
|
Rear suspension
|
Double A-Arm |
|
Rear wheel travel
|
254 mm (10.0 inches) |
|
Front tire
|
28/9-14 |
|
Rear tire
|
28/9-14 |
|
Front brakes
|
Single disc. Hydraulic |
|
Rear brakes
|
Single disc. Hydraulic |
|
Physical measures and capacities |
|
Dry weight
|
328.9 kg (725.1 pounds) |
|
Overall height
|
1316 mm (51.8 inches) |
|
Overall length
|
2154 mm (84.8 inches) |
|
Overall width
|
1206 mm (47.5 inches) |
|
Ground clearance
|
356 mm (14.0 inches) |
|
Wheelbase
|
1270 mm (50.0 inches) |
|
Fuel capacity
|
21.60 litres (5.71 US gallons) |
|
Other specifications |
|
Color options
|
Lime |
|
Comments
|
2/4WD with reverse. EBS. High/low range. Diff lock. |
