| Arctic Cat's profilation of this bike |
| Find your place in the great outdoors with an ATV that’s perfectly suited to your trail riding style. Whatever these machines set their minds to, they do it. And nothing gets in their way. |
|
General information |
|
Model name
|
Arctic Cat 425i SE |
|
Model year
|
2012 |
|
Category
|
ATV |
|
Rating
|
2.5 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
443.0 ccm (27.03 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Bore x stroke
|
89.0 x 71.2 mm (3.5 x 2.8 inches) |
|
Valves per cylinder
|
4 |
|
Fuel system
|
Injection. EFI |
|
Fuel control
|
Single Overhead Cams (SOHC) |
|
Cooling system
|
Liquid |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Driveline
|
Automatic CVT with EBS, Hi/Lo Range and Reverse. 2/4 WD |
|
Exhaust system
|
18 amps alternator |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Double A-Arm |
|
Front wheel travel
|
178 mm (7.0 inches) |
|
Rear suspension
|
Double A-Arm |
|
Rear wheel travel
|
178 mm (7.0 inches) |
|
Front tire
|
25/8-12 |
|
Rear tire
|
25/10-12 |
|
Front brakes
|
Single disc. Hydraulic |
|
Rear brakes
|
Single disc. Hydraulic |
|
Seat
|
Dual seat |
|
Physical measures and capacities |
|
Dry weight
|
278.0 kg (612.9 pounds) |
|
Overall height
|
1176 mm (46.3 inches) |
|
Overall length
|
2116 mm (83.3 inches) |
|
Overall width
|
1130 mm (44.5 inches) |
|
Ground clearance
|
261 mm (10.3 inches) |
|
Fuel capacity
|
16.30 litres (4.31 US gallons) |
|
Other specifications |
|
Color options
|
Black |
|
Instruments
|
Digital fuel gauge |
|
Carrying capacity
|
Front Rack Capacity 75 lb. / 34 kg. Rear Rack Capacity 150 lb. / 68.1 kg. Towing Capacity 1,050 lbs / 476.3 kg |
