| Arctic Cat's profilation of this bike |
| Fully-independent Suspension. Dual Taillights W/backup Lights. Durable Metal Racks. |
| General information |
|---|
| Model: | Arctic Cat 425i |
| Year: | 2012 |
| Category: | ATV |
| Rating: | 71.3 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 443.00 ccm (27.03 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Bore x stroke: | 89.0 x 71.2 mm (3.5 x 2.8 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Injection |
| Fuel control: | Single Overhead Cams (SOHC) |
| Cooling system: | Liquid |
| Gearbox: | Automatic |
Transmission type,
final drive: | Belt |
| Driveline: | Automatic CVT with EBS, Hi/Lo Range and Reverse. 2/4 WD |
| Exhaust system: | 18 amps alternator |
| Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Double A-Arm |
| Front wheel travel: | 178 mm (7.0 inches) |
| Rear suspension: | Double A-Arm |
| Rear wheel travel: | 178 mm (7.0 inches) |
| Front tyre: | 25/8-12 |
| Rear tyre: | 25/10-12 |
| Front brakes: | Single disc. Hydraulic |
| Rear brakes: | Single disc. Hydraulic |
| Physical measures and capacities |
|---|
| Dry weight: | 278.0 kg (612.9 pounds) |
| Overall height: | 1,176 mm (46.3 inches) |
| Overall length: | 2,116 mm (83.3 inches) |
| Overall width: | 1,130 mm (44.5 inches) |
| Ground clearance: | 261 mm (10.3 inches) |
| Fuel capacity: | 16.30 litres (4.31 gallons) |
| Other specifications |
|---|
| Color options: | Red, Green |
| Starter: | Electric |
| Instruments: | Digital |
| Carrying capacity: | Front Rack Capacity 75 lb. / 34 kg. Rear Rack Capacity 150 lb. / 68.1 kg. Towing Capacity 1,050 lbs / 476.3 kg |
