| Aprilia's profilation of this bike |
| Four valve timing and the fluid dynamic efficiency of the head have brought incredible benefits in terms of engine speed and performance, which are now on a par with a two stroke engine. |
|
General information |
|
Model
|
Aprilia Scarabeo 100 |
|
Year
|
2012 |
|
Category
|
Scooter |
|
Rating
|
Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
|
Engine and transmission |
|
Displacement
|
96.2 ccm (5.87 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Compression
|
10.5:1 |
|
Bore x stroke
|
50.0 x 49.0 mm (2.0 x 1.9 inches) |
|
Fuel system
|
Carburettor. Dell Ortho |
|
Fuel control
|
Overhead Cams (OHC) |
|
Ignition
|
CDI with variable advance |
|
Lubrication system
|
Separate oil petrol pump mixer |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Belt (final drive) |
|
Clutch
|
Automatic dry centifuge with damper buffers |
|
Emission details
|
Euro III |
|
Exhaust system
|
Catalysed |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Telescopic hydraulic fork |
|
Front wheel travel
|
78 mm (3.1 inches) |
|
Rear suspension
|
Single hydraulic shock absorber pivoting on engine-transmission assembly |
|
Rear wheel travel
|
82 mm (3.2 inches) |
|
Front tire
|
80/80-16 |
|
Rear tire
|
90/80-16 |
|
Front brakes
|
Single disc. Floating caliper |
|
Diameter
|
220 mm (8.7 inches) |
|
Rear brakes
|
Expanding brake (drum brake) |
|
Diameter
|
140 mm (5.5 inches) |
|
Physical measures and capacities |
|
Overall height
|
1270 mm (50.0 inches) |
|
Overall length
|
1905 mm (75.0 inches) |
|
Overall width
|
705 mm (27.8 inches) |
|
Wheelbase
|
1250 mm (49.2 inches) |
|
Fuel capacity
|
8.00 litres (2.11 US gallons) |
|
Reserve fuel capacity
|
1.50 litres (0.40 US gallons) |
|
Other specifications |
|
Color options
|
White, Black, Grey, Giava, Red, Bronze
|
|
Starter
|
Electric & kick |
