| Aprilia's profilation of this bike |
| Evolution in the name of competitiveness: this is the mission of Aprilia’s RXV 5.5. Experience gained from Aprilia Racing’s excellent results in the Enduro World Championship has led to Aprilia designers and engineers transferring even more race technology into this amazing production motorcycle. |
| General information |
|---|
| Model: | Aprilia RXV 5.5 |
| Year: | 2012 |
| Category: | Super motard |
| Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 550.0 ccm (33.56 cubic inches) |
| Engine type: | V2, four-stroke |
| Engine details: | 77° V twin. Titanium valves. |
| Valves per cylinder: | 4 |
| Fuel system: | Injection. Integrated electronic engine management system controlling ignition and fuel injection, with two power mappings. Throttle body: 40 mm. |
| Fuel control: | Single Overhead Cams (SOHC) |
| Ignition: | Electronic. |
| Lubrication system: | Dry sump with external oil tank. Separate gearbox lubrication. |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Cable operated multi-plate wet clutch. |
| Emission details: | Euro 3 lateral exhaust. Conforms to FIM regulations for 2009. |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Chrome-molybdenum steel perimeter frame with aluminium alloy vertical members. Lightweight rear frame. |
| Rake (fork angle): | 27.0° |
| Front suspension: | 48 mm upside down fork with two adjustments. |
| Rear suspension: | Aluminium swingarm with cast body and hydroformed members. Hydraulic monoshock with compression and rebound adjustment. |
| Front tyre: | 90/90-21 |
| Rear tyre: | 140/80-18 |
| Front brakes: | Single disc. Floating disc in stainless steel with aluminium flange. Nissin floating caliper. |
| Diameter: | 270 mm (10.6 inches) |
| Rear brakes: | Single disc. Stainless steel disc with floating caliper |
| Diameter: | 240 mm (9.4 inches) |
| Wheels: | Black anodised aluminium alloy. |
| Physical measures and capacities |
|---|
| Seat height: | 918 mm (36.1 inches) If adjustable, lowest setting. |
| Overall length: | 2220 mm (87.4 inches) |
| Overall width: | 800 mm (31.5 inches) |
| Ground clearance: | 396 mm (15.6 inches) |
| Wheelbase: | 1495 mm (58.9 inches) |
| Fuel capacity: | 7.80 litres (2.06 gallons) |
| Other specifications |
|---|
| Color options: | Off white |
| Starter: | Electric |
