Aprilia RSV4 Factory APRC 20132013 Aprilia RSV4 Factory APRC specifications, pictures, reviews and rating |
| Aprilia's profilation of this bike |
| Aprilia´s technological supremacy meant that every aspect of the electronic management system for the RSV4 Factory, with which Max Biaggi dominated the 2010 World Superbike Championship, could be developed in house. As a result of the innovative know how developed on the circuit and the close collaboration between the team, the Racing Division and the manufacturing division, the transfer of this technology from the track to production was practically instantaneous. |
| General information | |
|---|---|
| Model | Aprilia RSV4 Factory APRC |
| Year | 2013 |
| Category | Sport |
| Rating | 3.4 Check out the detailed rating of racing track capabilities, engine performance, accident risk, etc. Compare with any other bike. |
| Engine and transmission | |
| Displacement | 999.6 ccm (61.00 cubic inches) |
| Engine type | V4, four-stroke |
| Engine details | Longitudinal 65° V-4 cylinder |
| Power | 180.0 HP (131.4 kW)) @ 12500 RPM |
| Torque | 115.0 Nm (11.7 kgf-m or 84.8 ft.lbs) @ 10000 RPM |
| Compression | 13.0:1 |
| Bore x stroke | 78.0 x 52.3 mm (3.1 x 2.1 inches) |
| Valves per cylinder | 4 |
| Fuel system | Injection. Airbox with front dynamic air intakes. Variable length intake ducts controlled via ECU. 4 Weber-Marelli 48-mm throttle bodies with 8 injectors and latest generation Ride-by-Wire engine management. Choice of three different engine maps selectable by the ri |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Ignition | Magneti Marelli digital electronic ignition system integrated in engine control system, with one spark plug per cylinder and “stick-coilâ€-type coils |
| Lubrication system | Wet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling) |
| Cooling system | Liquid |
| Gearbox | 6-speed |
| Transmission type | Chain (final drive) |
| Clutch | Multi-disc oil-bath, with mechanical slipper system |
| Driveline | Primary: Straight cut gears and integrated flexible coupling, drive ratio: 73/44 (1,659) . Final: Chain: Drive ratio: 40/16 (2,5) . |
| Exhaust system | System 4 into 2 into 1 layout, single oxygen sensor, lateral single silencer with engine control unit-controlled butterfly valve and integrated trivalent catalytic converter (Euro 3) |
| Chassis, suspension, brakes and wheels | |
| Frame type | Twin-spar adjustable aluminium frame, with castings and pressings. |
| Rake (fork angle) | 24.5° |
| Trail | 105 mm (4.1 inches) |
| Front suspension | Ohlins Racing upside-down fork, 43-mm stanchions (with Tin surface treatment). Low profile forged aluminium radial caliper mountings. Completely adjustable spring preload and hydraulic compression and rebound damping. Wheel travel: 120 mm |
| Front wheel travel | 120 mm (4.7 inches) |
| Rear suspension | Twin sided aluminium swingarm |
| Rear wheel travel | 130 mm (5.1 inches) |
| Front tire | 120/70-ZR17 |
| Rear tire | 200/55-ZR17 |
| Front brakes | Double disc. Floating stainless steel disc |
| Diameter | 320 mm (12.6 inches) |
| Rear brakes | Single disc. Floating calliper with two 32mm isolated pistons |
| Diameter | 220 mm (8.7 inches) |
| Wheels | Forged aluminium alloy rims, completely machined, 5 split spokes. Front:3.5”X17” Rear: 6”X17” |
| Physical measures and capacities | |
| Dry weight | 179.0 kg (394.6 pounds) |
| Power/weight ratio | 1.0056 HP/kg |
| Seat height | 845 mm (33.3 inches) If adjustable, lowest setting. |
| Overall height | 1120 mm (44.1 inches) |
| Overall length | 2040 mm (80.3 inches) |
| Overall width | 735 mm (28.9 inches) |
| Ground clearance | 130 mm (5.1 inches) |
| Fuel capacity | 17.00 litres (4.49 US gallons) |
| Other specifications | |
| Color options | Racing Black/red/gold |
| Starter | Electric |
| Instruments | Dual display mode for instrument panel display: ROAD and RACE. |
| Electrical | Flywheel mounted 420W alternator with rare earth magnets. |
| Comments | APRC means ´Aprilia Performance Ride Control´. Aprilia Traction Control automatically adjusts to different types of tyres, with 8 settings conveniently selectable while racing from a joystick on the left handlebar without turning down the throttle. Optimised gear ratios for track performance. |
