Aprilia's profilation of this bike |
Motorcycling has taken a giant leap into the future with the Mana 850. Aprilia has always been ahead of its time, and often the first to develop technology other manufacturers have preferred to leave on the back burner. But never before has Aprilia’s forward thinking and talented R and D department dared to create such an innovative and revolutionary motorcycle. |
General information |
Motorcycle name
|
Aprilia Mana 850 |
Year
|
2012 |
Category
|
Naked bike |
Rating
|
3.3 See the detailed rating of engine performance, design and look, accident risk, etc. Compare with any other motorcycle. |
Engine and transmission |
Displacement
|
839.3 ccm (51.21 cubic inches) |
Engine type
|
V2, four-stroke |
Engine details
|
Aprilia 90° longitudinal V twin |
Power
|
75.1 HP (54.8 kW)) @ 8000 RPM |
Torque
|
73.0 Nm (7.4 kgf-m or 53.8 ft.lbs) @ 5000 RPM |
Compression
|
10.0:1 |
Bore x stroke
|
88.0 x 69.0 mm (3.5 x 2.7 inches) |
Valves per cylinder
|
4 |
Fuel system
|
Injection. Integrated engine management system. Weber Marelli electronic fuel injection with one 38 mm throttle body |
Fuel control
|
Double Overhead Cams/Twin Cam (DOHC) |
Ignition
|
Digital electronic ignition, with two spark plugs per cylinder, integrated with fuel injection system |
Lubrication system
|
Dry sump with separate oil reservoir |
Cooling system
|
Liquid |
Gearbox
|
Automatic |
Transmission type
|
Chain (final drive) |
Clutch
|
Automatic |
Driveline
|
Primary drive: Belt. Final drive: Chain |
Exhaust system
|
Two in one system in 100% stainless steel with three-way catalytic converter and Lambda probe |
Chassis, suspension, brakes and wheels |
Frame type
|
High strength steel trellis |
Rake (fork angle)
|
24.0° |
Trail
|
103 mm (4.1 inches) |
Front suspension
|
43 mm upside-down fork. |
Front wheel travel
|
120 mm (4.7 inches) |
Rear suspension
|
Aluminium alloy single-piece swingarm. Hydraulic shock absorber adjustable in spring preload and rebound damping. |
Rear wheel travel
|
125 mm (4.9 inches) |
Front tire
|
120/70-17 |
Rear tire
|
180/55-17 |
Front brakes
|
Double disc |
Diameter
|
320 mm (12.6 inches) |
Rear brakes
|
Single disc |
Diameter
|
260 mm (10.2 inches) |
Wheels
|
Aluminium alloy. Front: 3.50 x 17´ Rear: 6.00 x 17´ |
Physical measures and capacities |
Seat height
|
800 mm (31.5 inches) If adjustable, lowest setting. |
Overall height
|
1130 mm (44.5 inches) |
Overall length
|
2080 mm (81.9 inches) |
Overall width
|
800 mm (31.5 inches) |
Wheelbase
|
1463 mm (57.6 inches) |
Fuel capacity
|
16.00 litres (4.23 US gallons) |
Other specifications |
Color options
|
Red, white, black |
Starter
|
Electric |
Electrical
|
Generator: 450 W at 6000 rpm |
