| American Eagle's profilation of this bike |
| The Raven is American Eagles new Retro Style Springer. This Entry Level old school bike is still equipped with American Eagle top of the line features, yet made it an affordable custom production motorcycle. |
| General information |
|---|
| Model | American Eagle Raven |
| Year | 2009 |
| Category | Custom / cruiser |
| Rating | 2.7 See the detailed rating of design and look, maintenance cost, engine performance, etc. Compare with any other bike. |
| Engine and transmission |
|---|
| Displacement | 1573.0 ccm (95.98 cubic inches) |
| Engine type | V2, four-stroke |
| Fuel system | Carburettor |
| Ignition | Solid state ignition box with diagnostics |
| Gearbox | 5-speed |
| Transmission type | Belt (final drive) |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type | Handcrafted Alloy Frame |
| Rake (fork angle) | 34.0° |
| Rear suspension | Chrome Adjustable Shocks |
| Front tire | 90/90-21 |
| Rear tire | 180/55-18 |
| Front brakes | Single disc. 4-piston cali |
| Rear brakes | Single disc |
| Physical measures and capacities |
|---|
| Dry weight | 272.2 kg (600.0 pounds) |
| Other specifications |
|---|
| Color options | Custom paint scheme |
| Starter | Electric |
| Comments | Optional 2 up passenger seat. |
| Update specs | Report missing specs or required updates. |
| Further information |
|---|
| Insurance costs |
|
| Parts finder |
Check out our overview of motorcycle webshops at Bikez.info. |
| Maintenance | Find parts, fluids. filters, maintenance tools and service manuals at Amazon.com. |
| Ask questions | Join the 09 American Eagle Raven discussion group or the general American Eagle discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
