General information |
|
Model name
|
Aeon Overland 180 |
|
Model year
|
2010 |
|
Category
|
ATV |
|
Rating
|
2.8 Check out the detailed rating of reliability, maintenance costs, value for money, etc. Compare with any other motorcycle. |
|
Engine and transmission |
|
Displacement
|
169.0 ccm (10.31 cubic inches) |
|
Engine type
|
Single cylinder, four-stroke |
|
Power output
|
8.7 HP (6.4 kW)) @ 8200 RPM |
|
Torque
|
10.2 Nm (1.0 kgf-m or 7.5 ft.lbs) @ 4500 RPM |
|
Compression
|
9.1:1 |
|
Bore x stroke
|
61.0 x 57.8 mm (2.4 x 2.3 inches) |
|
Fuel system
|
Carburettor |
|
Ignition
|
C.D.I. |
|
Lubrication system
|
Wet sump, oil pump pressurized |
|
Cooling system
|
Air |
|
Gearbox
|
Automatic |
|
Transmission type
|
Shaft drive (cardan) (final drive) |
|
Clutch
|
Centrifugal clutch |
|
Chassis, suspension, brakes and wheels |
|
Front suspension
|
Dual hydraulic shock, Double wishbone |
|
Rear suspension
|
Single hydraulic shock, Unit swing arm |
|
Front tire
|
21/7-10 |
|
Rear tire
|
22/10-8 |
|
Front brakes
|
Expanding brake (drum brake) |
|
Rear brakes
|
Single disc |
|
Physical measures and capacities |
|
Dry weight
|
178.0 kg (392.4 pounds) |
|
Power/weight ratio
|
0.0489 HP/kg |
|
Seat height
|
770 mm (30.3 inches) If adjustable, lowest setting. |
|
Overall height
|
1170 mm (46.1 inches) |
|
Overall length
|
1740 mm (68.5 inches) |
|
Overall width
|
1050 mm (41.3 inches) |
|
Ground clearance
|
150 mm (5.9 inches) |
|
Wheelbase
|
1065 mm (41.9 inches) |
|
Fuel capacity
|
8.00 litres (2.11 US gallons) |
|
Oil capacity
|
1.20 litres (1.27 US quarts) |
|
Other specifications |
|
Color options
|
Green, red |
|
Starter
|
Electric |
