| General moped information |
|---|
| Model: | Adly FC-25 II 2nd Gen E-bike |
| Year: | 2010 |
| Category: | Scooter |
| Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
| Engine and transmission |
|---|
| Engine type: | Electric |
| Cooling system: | Air |
| Gearbox: | Automatic |
| Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Dual spring |
| Rear suspension: | Oil damped single shock |
| Front tyre: | 90/90-6 |
| Rear tyre: | 90/90-6 |
| Front brakes: | Expanding brake (drum brake) |
| Rear brakes: | Expanding brake (drum brake) |
| Physical measures and capacities |
|---|
| Dry weight: | 52.0 kg (114.6 pounds) |
| Overall height: | 950 mm (37.4 inches) |
| Overall length: | 1,240 mm (48.8 inches) |
| Overall width: | 550 mm (21.7 inches) |
| Wheelbase: | 890 mm (35.0 inches) |
| Other specifications |
|---|
| Color options: | Red |
| Starter: | Electric |
| Comments: | 12V 26AH battery. Charges 110-240V 5 Amp/h. Made in Taiwan. |
