| General information |
|---|
| Model: | Scorpa SR 280 |
| Year: | 2012 |
| Category: | Trial |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 272.00 ccm (16.60 cubic inches) |
| Engine type: | Single cylinder, two-stroke |
| Bore x stroke: | 76.0 x 60.0 mm (3.0 x 2.4 inches) |
| Fuel system: | Carburettor. Dell´Orto PHBL 26BL |
| Fuel control: | Single Overhead Cams (SOHC) |
| Ignition: | C.D.I. |
| Lubrication system: | 2% mixture |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Wet multidisk |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Steel tube |
| Front suspension: | Marzocchi 40 mm hydraulic fork, adjustable compression and rebond damping |
| Front wheel travel: | 177 mm (7.0 inches) |
| Rear suspension: | Sachs adjustable hydraulic monoshock |
| Rear wheel travel: | 165 mm (6.5 inches) |
| Front tyre: | 1.60-21 |
| Rear tyre: | 2.15-18 |
| Front brakes: | Single disc. Floating Wave disk with AJP 4-piston calipers |
| Front brakes diameter: | 182 mm (7.2 inches) |
| Rear brakes: | Single disc. Floating Wave disk with AJP 2-piston calipers |
| Rear brakes diameter: | 150 mm (5.9 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 70.0 kg (154.3 pounds) |
| Weight incl. oil, gas, etc: | 73.0 kg (160.9 pounds) |
| Seat height: | 699 mm (27.5 inches) If adjustable, lowest setting. |
| Overall length: | 2,050 mm (80.7 inches) |
| Ground clearance: | 295 mm (11.6 inches) |
| Wheelbase: | 1,345 mm (53.0 inches) |
| Fuel capacity: | 2.60 litres (0.69 gallons) |
| Oil capacity: | 1.00 litres (0.07 quarts) |
| Other specifications |
|---|
| Color options: | Orange/grey/white |
| Starter: | Kick |
| Comments: | French made bike. |
