| Hyosung's profilation of this bike |
| An affordable road legal quad that offers a smooth power delivery and a fully adjustable suspension to give maximum traction. |
| General information |
|---|
| Model: | Hyosung Rapier 450 Quad |
| Year: | 2011 |
| Category: | ATV |
| Rating: | 75.2 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 448.80 ccm (27.39 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Power: | 50.00 HP (36.5 kW)) @ 8500 RPM |
| Torque: | 47.64 Nm (4.9 kgf-m or 35.1 ft.lbs) @ 7000 RPM |
| Compression: | 12.0:1 |
| Bore x stroke: | 96.0 x 62.0 mm (3.8 x 2.4 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Carburettor |
| Fuel control: | Double Overhead Cams/Twin Cam (DOHC) |
| Lubrication system: | Semi dry sump |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Wet, Multiplate |
| Driveline: | Chain 520, With reverse. |
| Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Independent double A-arm, |
| Rear suspension: | Aluminum alloy swing arm, |
| Front tyre: | 175/75-10 |
| Rear tyre: | 255/55-9 |
| Front brakes: | Double disc |
| Front brakes diameter: | 170 mm (6.7 inches) |
| Rear brakes: | Single disc |
| Rear brakes diameter: | 240 mm (9.4 inches) |
| Physical measures and capacities |
|---|
| Overall height: | 1,155 mm (45.5 inches) |
| Overall length: | 1,835 mm (72.2 inches) |
| Overall width: | 1,170 mm (46.1 inches) |
| Ground clearance: | 260 mm (10.2 inches) |
| Wheelbase: | 1,250 mm (49.2 inches) |
| Fuel capacity: | 11.00 litres (2.91 gallons) |
| Other specifications |
|---|
| Color options: | Red/black |
| Starter: | Electric |
| Factory warranty: | 24 months |
| Further information |
|---|
| Insurance costs | Get estimated US insurance cost with a quote from Allstate Motorcycle Insurance.
|
| Parts finder |
Chaparral provides online schematics & OEM parts for the US.
Motorcycle Superstore provides an easy-to-use parts finder. Ships to the US, Canada, UK and Australia.
MotoSport.com ships motorcycle parts and accessories to most countries.
Sixity.com has low prices and free shipping on ATV and motorcycle parts to the US.
Also check out our overview of motorcycle webshops at Bikez.info. |
| ATV parts | Sixity.com sells ATV parts with free shipping to the US. |
| Loans, tests, etc | Search the web for dealers, loan costs, tests, customizing, etc. |
| Ask questions | Join the 11 Hyosung Rapier 450 Quad discussion group. |
| Related bikes | List related bikes for comparison of specs. |
|
|
|
Rating sample for this Hyosung bike
|
Touring capabilities for the 2011 Hyosung Rapier 450 Quad:
 (70.0 out of 100)
Click here for complete rating. You can also compare bikes.
|
|
