| General information |
|---|
| Model: | Honda XR 650 R |
| Year: | 2006 |
| Category: | Enduro / offroad |
| Rating: | 72.4 out of 100. Show full rating and compare with other bikes |
| Price as new (MSRP): | US$ 6299. Prices depend on country, taxes, accessories, etc. |
| Engine and transmission |
|---|
| Displacement: | 649.00 ccm (39.60 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Compression: | 10.0:1 |
| Bore x stroke: | 100.0 x 82.6 mm (3.9 x 3.3 inches) |
| Fuel system: | Carburettor. Keihin 40mm piston-valve |
| Fuel control: | Single Overhead Cams (SOHC) |
| Ignition: | Solid-state CD with electronic advance |
| Lubrication system: | Dry sump |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Chassis, suspension, brakes and wheels |
|---|
| Rake (fork angle): | 27.8° |
| Trail: | 111 mm (4.4 inches) |
| Front suspension: | 46mm leading-axle Kayaba cartridge fork with compression- and rebound-damping adjustability |
| Front wheel travel: | 284 mm (11.2 inches) |
| Rear suspension: | Pro-Link Kayaba single-shock with spring-preload, compression- and rebound-damping adjustability |
| Rear wheel travel: | 307 mm (12.1 inches) |
| Front tyre: | 80/70-21 |
| Rear tyre: | 110/90-18 |
| Front brakes: | Single disc |
| Front brakes diameter: | 240 mm (9.4 inches) |
| Rear brakes: | Single disc |
| Rear brakes diameter: | 240 mm (9.4 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 125.6 kg (277.0 pounds) |
| Seat height: | 935 mm (36.8 inches) If adjustable, lowest setting. |
| Ground clearance: | 305 mm (12.0 inches) |
| Wheelbase: | 1,481 mm (58.3 inches) |
| Fuel capacity: | 9.84 litres (2.60 gallons) |
| Other specifications |
|---|
| Color options: | Red |
| Comments: | Model ID: XR650R |
