13 Honda CRF230F specificationsHonda CRF230F 2013


2013 Honda CRF230F photo
Picture credits - Honda. Click to submit more pictures.
   Show big 2013 Honda CRF230F image
2013 Honda CRF230F

Discuss this bike
Rate this motorbike
This bike's rating
Write a review

Sell this motorcycle
Such bikes for sale

Tip a friend
List related bikes



Honda's profilation of this bike
Throw your leg over the saddle of the CRF230F, push the electric starter, and have a blast. You don’t have to worry about breaking down or excessive maintenance, you can jump on the CRF230F with its durable six-speed transmission and plush, long travel suspension and leave the on-road world in the dust.

General information
Model:Honda CRF230F
Year:2013
Category:Enduro / offroad
Rating:Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating.
Price as new (MSRP):US$ 4170. Prices depend on country, taxes, accessories, etc.
Engine and transmission
Displacement:223.00 ccm (13.61 cubic inches)
Engine type:Single cylinder, four-stroke
Compression:9.0:1
Bore x stroke:65.5 x 66.2 mm (2.6 x 2.6 inches)
Fuel system:Carburettor. 26mm piston-valve carburetor
Fuel control:SOHC
Ignition:CD
Cooling system:Air
Gearbox:6-speed
Transmission type,
final drive:
Chain
Driveline:#520 O-ring-sealed chain; 13T/50T
Emission details:Meets current California Air Resources Board (CARB) and EPA off-road emissions standards.
Chassis, suspension, brakes and wheels
Rake (fork angle):27.3°
Trail:112 mm (4.4 inches)
Front suspension:37mm leading-axle Showaż fork
Front suspension travel:241 mm (9.5 inches)
Rear suspension:Pro-Link® Showa single shock with spring-preload adjustability; 9.0 inches travel
Rear tyre dimensions:100/100-18
Front brakes:Single disc
Front brakes diameter:240 mm (9.4 inches)
Rear brakes:Expanding brake (drum brake)
Physical measures and capacities
Weight incl. oil, gas, etc:112.9 kg (249.0 pounds)
Seat height:866 mm (34.1 inches) If adjustable, lowest setting.
Ground clearance:297 mm (11.7 inches)
Wheelbase:1,374 mm (54.1 inches)
Fuel capacity:7.19 litres (1.90 gallons)
Other specifications
Starter:Electric & kick
Color options:Red
Comments:Model ID: CRF230F
