| General moped information |
|---|
| Model: | Giantco Stealth Naked 2T |
| Year: | 2009 |
| Category: | Scooter |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 49.20 ccm (3.00 cubic inches) |
| Engine type: | In-line three, two-stroke |
| Power: | 2.46 HP (1.8 kW)) @ 7000 RPM |
| Torque: | 4.30 Nm (0.4 kgf-m or 3.2 ft.lbs) @ 7000 RPM |
| Compression: | 6.9:1 |
| Bore x stroke: | 40.0 x 39.2 mm (1.6 x 1.5 inches) |
| Cooling system: | Air |
Transmission type,
final drive: | Belt |
| Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Oil damped telescopic fork |
| Rear suspension: | Oil damped coil spring with Gas Chamber |
| Front tyre dimensions: | 110/70-12 |
| Rear tyre dimensions: | 120/70-12 |
| Front brakes: | Single disc |
| Rear brakes: | Expanding brake (drum brake) |
| Physical measures and capacities |
|---|
| Dry weight: | 90.0 kg (198.4 pounds) |
| Power/weight ratio: | 0.0273 HP/kg |
| Overall height: | 1,070 mm (42.1 inches) |
| Overall length: | 1,830 mm (72.0 inches) |
| Wheelbase: | 1,270 mm (50.0 inches) |
| Fuel capacity: | 4.20 litres (1.11 gallons) |
| Other specifications |
|---|
| Starter: | Electric & kick |
| Comments: | Chinese scooter. Also available with a 4 stroke engine. |
