| General information |
|---|
| Model: | Erik Buell Racing 1125R DSB |
| Year: | 2010 |
| Category: | Sport |
| Rating: | 61.2 out of 100. Show full rating and compare with other bikes |
| Price as new (MSRP): | US$ 15900. Prices depend on country, taxes, accessories, etc. |
| Engine and transmission |
|---|
| Displacement: | 1126.00 ccm (68.71 cubic inches) |
| Engine type: | V2, four-stroke |
| Engine details: | 72 and #730; V-Twin |
| Power: | 140.00 HP (102.2 kW)) @ 10800 RPM |
| Torque: | 108.48 Nm (11.1 kgf-m or 80.0 ft.lbs) @ 8500 RPM |
| Compression: | 12.6:1 |
| Bore x stroke: | 103.0 x 67.5 mm (4.1 x 2.7 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Injection. IDS Technology DDFI 3 electronic fuel injection and engine management system, fully programmable, 61mm throttle bodies, single injector, PWM fuel pump |
| Fuel control: | DOHC |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Multiplate with vacuum operated slipper or optional mechanical slipper at extra charge |
| Driveline: | 520 Chain. Primary drive: Straight cut gear, 1.806 ratio. |
| Exhaust system: | Stainless steel ultralight 2 into 1 system. |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Light alloy large section beam with integral fuel cell. Subframe: Light alloy tubular. |
| Rake (fork angle): | 21.8° |
| Front suspension: | Showa 47mm inverted fork with race cartridge, fully adjustable. |
| Front suspension travel: | 120 mm (4.7 inches) |
| Rear suspension: | Light alloy swingarm with Showa Race damper, adjustable compression, rebound and ride height. |
| Rear suspension travel: | 127 mm (5.0 inches) |
| Front tyre dimensions: | 120/70-ZR17 |
| Rear tyre dimensions: | 190/55-ZR17 |
| Front brakes: | Double disc. Semi floating ISO multi-fin rotor with 8 piston ZTL2 caliper |
| Front brakes diameter: | 388 mm (15.3 inches) |
| Rear brakes: | Single disc. Lightweight disc, 2 piston caliper |
| Rear brakes diameter: | 205 mm (8.1 inches) |
| Wheels: | Front 6 spoke ZTL, 3.50 x 17. Rear 6 spoke cast aluminum, 5.50 x 17. |
| Physical measures and capacities |
|---|
| Dry weight: | 176.9 kg (390.0 pounds) |
| Power/weight ratio: | 0.7914 HP/kg |
| Wheelbase: | 1,400 mm (55.1 inches) |
| Fuel capacity: | 20.06 litres (5.30 gallons) |
| Other specifications |
|---|
| Color options: | Black/silver |
| Comments: | Racing bike not legal for street usage. Adjustable rake and wheelbase. |
