| Yamaha's profilation of this bike |
| Set your imagination free: the JogR takes the effort out of riding but keeps all the fun. It’s lightweight, but still strong enough to handle the city. And it´s speedy, with enough agility to beat the traffic. |
| General moped information |
|---|
| Model: | Yamaha JogR | | Year: | 2012 | | Category: | Scooter | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Engine and transmission |
|---|
| Displacement: | 49.00 ccm (2.99 cubic inches) | | Engine type: | Single cylinder, two-stroke | | Power: | 2.68 HP (2.0 kW)) @ 7000 RPM | | Torque: | 2.46 Nm (0.3 kgf-m or 1.8 ft.lbs) @ 7000 RPM | | Compression: | 11.6:1 | | Bore x stroke: | 40.0 x 39.2 mm (1.6 x 1.5 inches) | | Fuel system: | Carburettor. Gurtner PY12 | | Fuel control: | SOHC | | Ignition: | CDI | | Lubrication system: | Separate lubrication | | Cooling system: | Air | | Gearbox: | Automatic | Transmission type,
final drive: | Belt | | Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Telescopic fork | | Front suspension travel: | 70 mm (2.8 inches) | | Rear suspension: | Unit Swing | | Front tyre dimensions: | 110/70-12 | | Rear tyre dimensions: | 120/70-12 | | Front brakes: | Single disc | | Front brakes diameter: | 190 mm (7.5 inches) | | Rear brakes: | Expanding brake (drum brake) | | Rear brakes diameter: | 110 mm (4.3 inches) | | Wheels: | 6-spoke aluminium wheels | | Physical measures and capacities |
|---|
| Weight incl. oil, gas, etc: | 81.0 kg (178.6 pounds) | | Seat height: | 770 mm (30.3 inches) If adjustable, lowest setting. | | Overall height: | 1,065 mm (41.9 inches) | | Overall length: | 1,740 mm (68.5 inches) | | Overall width: | 675 mm (26.6 inches) | | Ground clearance: | 132 mm (5.2 inches) | | Wheelbase: | 1,210 mm (47.6 inches) | | Fuel capacity: | 5.50 litres (1.45 gallons) | | Other specifications |
|---|
| Starter: | Electric & kick | | Carrying capacity: | Storage compartment and luggage hook | | Color options: | White/blue, purple/black | | Further information |
|---|
