| General information |
|---|
| Model: | TM Racing MX 300 |
| Year: | 2008 |
| Category: | Cross / motocross |
| Rating: | 70.4 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 294.00 ccm (17.94 cubic inches) |
| Engine type: | Single cylinder, two-stroke |
| Bore x stroke: | 72.0 x 72.0 mm (2.8 x 2.8 inches) |
| Fuel system: | Carburettor. Keihin PWM 38 |
| Ignition: | Kokusan CDI Electronic with variable advance |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Clutch: | Multiple-disk in oil bath with hydraulic control |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Perimetral aluminium section |
| Front suspension: | Marzocchi USD 50mm ( optional Ohlins 48mm ) |
| Rear suspension: | Sachs Boge (optional Ohlins ) |
| Front tyre dimensions: | 100/90-21 |
| Rear tyre dimensions: | 110/90-19 |
| Front brakes: | Single disc |
| Front brakes diameter: | 270 mm (10.6 inches) |
| Rear brakes: | Single disc |
| Rear brakes diameter: | 245 mm (9.6 inches) |
| Physical measures and capacities |
|---|
| Fuel capacity: | 8.70 litres (2.30 gallons) |
