| General information |
|---|
| Model: | Saxon Warlord |
| Year: | 2012 |
| Category: | Custom / cruiser |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 1566.00 ccm (95.56 cubic inches) |
| Engine type: | V2, four-stroke |
| Engine details: | 45 degree V-twin |
| Compression: | 10.1:1 |
| Bore x stroke: | 94.0 x 119.4 mm (3.7 x 4.7 inches) |
| Fuel system: | Carburettor. Minuni HSR 42 |
| Fuel control: | OHV |
| Ignition: | Electronic |
| Cooling system: | Air |
| Gearbox: | 6-speed |
Transmission type,
final drive: | Belt |
| Driveline: | Chain primary drive. Right-side drive. |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Stretch: 6 inch Downtube, 2 inch Backbone |
| Rake (fork angle): | 45.0° |
| Front suspension: | 41mm Telescopic 11 inch Over |
| Rear suspension: | Hidden shocks |
| Front tyre dimensions: | 90/90-21 |
| Rear tyre dimensions: | 260/60-18 |
| Front brakes: | Single disc. Bremo, 4-piston caliper |
| Rear brakes: | Single disc. Bremo, 2-piston caliper |
| Wheels: | 80 Spoke Wheels. Customizable. |
| Physical measures and capacities |
|---|
| Dry weight: | 285.3 kg (629.0 pounds) |
| Seat height: | 533 mm (21.0 inches) If adjustable, lowest setting. |
| Overall length: | 2,743 mm (108.0 inches) |
| Wheelbase: | 2,108 mm (83.0 inches) |
| Fuel capacity: | 17.03 litres (4.50 gallons) |
| Oil capacity: | 3.30 litres (0.22 quarts) |
| Other specifications |
|---|
| Starter: | Electric |
| Instruments: | Digital with integrated tach |
| Electrical: | 550 CCA battery. 32 Amp charger. |
| Seat: | Various options. |
| Factory warranty: | 2-Year Factory Warranty |
