| General information |
|---|
| Model: | Honda Stateline ABS | | Year: | 2011 | | Category: | Custom / cruiser | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Engine and transmission |
|---|
| Displacement: | 1312.00 ccm (80.06 cubic inches) | | Engine type: | V2, four-stroke | | Compression: | 9.2:1 | | Bore x stroke: | 89.5 x 104.3 mm (3.5 x 4.1 inches) | | Valves per cylinder: | 3 | | Fuel system: | Injection. PGM-FI with automatic enrichment circuit, one 38mm throttle body | | Fuel control: | SOHC | | Cooling system: | Liquid | | Gearbox: | 5-speed | Transmission type,
final drive: | Shaft drive (cardan) | | Emission details: | Meets current EPA standards. California version meets current California Air Resources Board (CARB) standards and may differ slightly due to emissions equipment. | | Chassis, suspension, brakes and wheels |
|---|
| Rake (fork angle): | 33.0° | | Front suspension: | 41mm fork | | Front suspension travel: | 102 mm (4.0 inches) | | Rear suspension: | Single shock | | Rear suspension travel: | 99 mm (3.9 inches) | | Front tyre dimensions: | 140/80-17 | | Rear tyre dimensions: | 170/80-15 | | Front brakes: | Single disc. Anti-lock braking (ABS) | | Front brakes diameter: | 336 mm (13.2 inches) | | Rear brakes: | Single disc. Anti-lock braking (ABS) | | Rear brakes diameter: | 296 mm (11.7 inches) | | Physical measures and capacities |
|---|
| Weight incl. oil, gas, etc: | 309.0 kg (681.2 pounds) | | Seat height: | 678 mm (26.7 inches) If adjustable, lowest setting. | | Wheelbase: | 1,781 mm (70.1 inches) | | Fuel capacity: | 16.65 litres (4.40 gallons) | | Reserve fuel capacity: | 4.00 litres (1.06 gallons) | | Other specifications |
|---|
| Starter: | Electric | | Factory warranty: | One year transferable, unlimited-mileage limited warranty | | Color options: | Black, Candy Dark Red | | Further information |
|---|
| Parts and accessories | Our partner CMSNL
ships low cost OEM motorcycle parts to
Australia, Austria, Bahamas, Belgium, Canada, China, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany,
Greece, Hong Kong, Hungary, Iceland, India, Ireland, Italy, Japan, Kuwait, Latvia, Lithuania, Luxembourg, Macedonia, Malta, Montenegro,
The Netherlands, New Zealand, Norway, Poland, Portugal, Serbia, Slovakia, Slovenia, South Africa, Spain, Sweden, Switzerland,
Taiwan, Ukraine, United Kingdom, The United States and more. Or check out parts and accessories from our other partners. |
| Ask questions | Join the 11 Honda Stateline ABS discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
