99 Honda CB 500 specificationsHonda CB 500 1999


1999 Honda CB 500 photo
Picture submitted by anonymous user.. Click to submit more pictures.
1999 Honda CB 500

Discuss this bike
Rate this motorbike
This bike's rating
Write a review

Sell this motorcycle
Such bikes for sale

Tip a friend
List related bikes



General information
Model:Honda CB 500
Year:1999
Category:Naked bike
Rating:60.8 out of 100. Show full rating and compare with other bikes
Engine and transmission
Displacement:499.00 ccm (30.45 cubic inches)
Engine type:Twin, four-stroke
Power:57.00 HP (41.6 kW)) @ 9500 RPM
Torque:34.70 Nm (3.5 kgf-m or 25.6 ft.lbs) @ 8000 RPM
Top speed:193.0 km/h (119.9 mph)
1/4 mile (0.4 km):13.500 seconds
Max RPM:10500
Valves per cylinder:4
Fuel system:Carburettor. Keihin 2 x 34 mm VP type
Fuel control:DOHC
Ignition:Digital transistorised with electronic advance
Cooling system:Liquid
Gearbox:6-speed
Transmission type,
final drive:
Chain
Clutch:Wet multi-plate, calbe-operated
Fuel consumption:5.50 litres/100 km (18.2 km/l or 42.77 mpg)
Greenhouse gases:127.6 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis, suspension, brakes and wheels
Frame type:Double cradle of tubular and box-section steel construction
Rake (fork angle):27.0
Trail:113 mm (4.4 inches)
Front suspension:37 mm oil-damped telescopic forks
Front suspension travel:115 mm (4.5 inches)
Rear suspension:Twin shoks acting on a steel, box-section swingarm
Rear suspension travel:117 mm (4.6 inches)
Front tyre dimensions:110/80-17 57H
Rear tyre dimensions:130/80-17 65H
Front brakes:Single disc. Nissin 2-piston sliding caliper
Front brakes diameter:296 mm (11.7 inches)
Rear brakes:Single disc. Brembo single piston sliding caliper
Rear brakes diameter:240 mm (9.4 inches)
Physical measures and capacities
Dry weight:173.0 kg (381.4 pounds)
Power/weight ratio:0.3295 HP/kg
Seat height:775 mm (30.5 inches) If adjustable, lowest setting.
Overall height:1,050 mm (41.3 inches)
Overall length:2,090 mm (82.3 inches)
Overall width:720 mm (28.3 inches)
Ground clearance:145 mm (5.7 inches)
Wheelbase:1,435 mm (56.5 inches)
Fuel capacity:18.00 litres (4.76 gallons)
Reserve fuel capacity:2.50 litres (0.66 gallons)
Oil capacity:3.10 litres (0.20 quarts)
Other specifications
Starter:Electric
Further information
Parts and accessories Our partner CMSNL ships low cost OEM motorcycle parts to Australia, Austria, Bahamas, Belgium, Canada, China, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hong Kong, Hungary, Iceland, India, Ireland, Italy, Japan, Kuwait, Latvia, Lithuania, Luxembourg, Macedonia, Malta, Montenegro, The Netherlands, New Zealand, Norway, Poland, Portugal, Serbia, Slovakia, Slovenia, South Africa, Spain, Sweden, Switzerland, Taiwan, Ukraine, United Kingdom, The United States and more. Or check out parts and accessories from our other partners.
Ask questionsJoin the 99 Honda CB 500 discussion group.
Insurance, loans, tests Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc.
Related bikesList related bikes for comparison of specs



Discussions for every bike

Bikez has discussion forums for every bike. View comments, questions and answers at the 1999 Honda CB 500 discussion group. You can sign up for e-mail notifications when other riders answer you. If you have extensive experience with the MC, please send us a review.

If you consider buying this bike, you should view the list of related motorbikes Look at photos. Compare technical specs. And check out the rating of the bike's engine performance, reliability, repair costs, etc. You can compare the rating with other bikes.


Rating sample for this Honda bike
Engine performance for the 1999 Honda CB 500:


(71.0 out of 100)

Click here for complete rating. You can also compare bikes.
