| Ducati's profilation of this bike |
| The Monster 796 is the perfect synthesis between sports performances, aesthetics and daily riding pleasure. Cared for in each single detail, it is the ideal bike for each riding style and represents the utmost evolution of the Monster family. |
| General information |
|---|
| Model: | Ducati Monster 796 | | Year: | 2013 | | Category: | Naked bike | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Engine and transmission |
|---|
| Displacement: | 803.00 ccm (49.00 cubic inches) | | Engine type: | V2, four-stroke | | Power: | 85.83 HP (62.6 kW)) @ 8250 RPM | | Torque: | 78.00 Nm (8.0 kgf-m or 57.5 ft.lbs) @ 6250 RPM | | Compression: | 11.0:1 | | Bore x stroke: | 88.0 x 66.0 mm (3.5 x 2.6 inches) | | Fuel system: | Injection. Siemens electronic fuel injection, 45mm throttle body | | Fuel control: | Desmodromic valve control | | Cooling system: | Air | | Gearbox: | 6-speed | Transmission type,
final drive: | Chain | | Clutch: | APTC wet multiplate with hydraulic control | | Driveline: | Chain; Front sprocket 15; Rear sprocket 39. Primary drive: Straight cut gears; Ratio 1.85. | | Emission details: | Euro 3 | | Exhaust system: | Lightweight 2-1-2 system with catalytic converter with twin lambda probes | | Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Tubular steel Trellis frame | | Rake (fork angle): | 24.0° | | Trail: | 87 mm (3.4 inches) | | Front suspension: | 43mm upside-down forks | | Rear suspension: | Progressive linkage with preload and rebound Sachs adjustable monoshock | | Front tyre dimensions: | 120/70-ZR17 | | Rear tyre dimensions: | 180/55-ZR17 | | Front brakes: | Double disc. Four-piston calipers. | | Front brakes diameter: | 320 mm (12.6 inches) | | Rear brakes: | Single disc. Two-piston calipers. | | Rear brakes diameter: | 245 mm (9.6 inches) | | Physical measures and capacities |
|---|
| Dry weight: | 167.0 kg (368.2 pounds) | | Weight incl. oil, gas, etc: | 187.0 kg (412.3 pounds) | | Power/weight ratio: | 0.5140 HP/kg | | Seat height: | 800 mm (31.5 inches) If adjustable, lowest setting. | | Wheelbase: | 1,450 mm (57.1 inches) | | Fuel capacity: | 15.00 litres (3.96 gallons) | | Other specifications |
|---|
| Starter: | Electric | | Instruments: | Digital unit displaying Speedometer, rev counter, clock, scheduled maintenance warning, oil temperature, trip fuel, lap time, warning light for low oil pressure, fuel level, fuel reserve, neutral, turn signals, overrev, immobilizer. Ready for DDA system. | | Factory warranty: | 2 years unlimited mileage | | Color options: | Black, red, white | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our other partners. |
| Ask questions | Join the 13 Ducati Monster 796 discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
