| Derbi's profilation of this bike |
| Big wheels to overcome every obstacle; its cycle parts are fast and stable for perfect riding: only a few of the ingredients of this perfect mix, both for daily use and extra-urban trips. |
| General information |
|---|
| Model: | Derbi Terra 125 | | Year: | 2009 | | Category: | Allround | | Rating: | 67.9 out of 100. Show full rating and compare with other bikes | | Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 124.20 ccm (7.58 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 4 | | Power: | 15.00 HP (10.9 kW)) | | Bore x stroke: | 58.0 x 47.0 mm (2.3 x 1.9 inches) | | Fuel system: | Carburettor. 30 mm | | Valves per cylinder: | 4 | | Ignition: | CDI | | Starter: | Electric | | Lubrication system: | Dry sump with integrated oil deposit | | Cooling system: | Liquid | | Gearbox: | 6-speed | | Clutch: | Multi-plate in oil bath | | Physical measures |
|---|
| Dry weight: | 117.0 kg (257.9 pounds) | | Seat height: | 795 mm (31.3 inches) If adjustable, lowest setting. | | Overall height: | 1,260 mm (49.6 inches) | | Overall length: | 2,144 mm (84.4 inches) | | Overall width: | 815 mm (32.1 inches) | | Wheelbase: | 1,440 mm (56.7 inches) | | Chassis and dimensions |
|---|
| Front suspension: | Hydraulic fork | | Front suspension travel: | 150 mm (5.9 inches) | | Rear suspension: | Mono-shock with adjustable spring pre-load. | | Front tyre dimensions: | 100/90-18 | | Rear tyre dimensions: | 130/80-17 | | Front brakes: | Single disc | | Front brakes diameter: | 280 mm (11.0 inches) | | Rear brakes: | Single disc | | Rear brakes diameter: | 220 mm (8.7 inches) | | Exhaust system: | Euro III | | Speed and acceleration |
|---|
| Power/weight ratio: | 0.1282 HP/kg | | Other specifications |
|---|
| Fuel capacity: | 12.00 litres (3.17 gallons) | | Color options: | Blue, yellow, red | | Comments: | Derbi is a Soanish brand | | Further information |
|---|
