| General information |
|---|
| Model: | Beta Evo 250 4T |
| Year: | 2013 |
| Category: | Trial |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 249.60 ccm (15.23 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Compression: | 11.5:1 |
| Bore x stroke: | 77.0 x 53.6 mm (3.0 x 2.1 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Carburettor. Mikuni |
| Ignition: | Electronic |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type,
final drive: | Chain |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Single wave aluminium beam |
| Front suspension: | Hydraulic fork with ø38 mm shaft |
| Front suspension travel: | 165 mm (6.5 inches) |
| Rear suspension: | Monoshock |
| Rear suspension travel: | 180 mm (7.1 inches) |
| Front tyre dimensions: | 2.75-21 |
| Rear tyre dimensions: | 4.00-18 |
| Front brakes: | Single disc. 4 piston caliper |
| Front brakes diameter: | 185 mm (7.3 inches) |
| Rear brakes: | Single disc. 2 piston caliper |
| Rear brakes diameter: | 150 mm (5.9 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 71.5 kg (157.6 pounds) |
| Seat height: | 680 mm (26.8 inches) If adjustable, lowest setting. |
| Overall height: | 1,115 mm (43.9 inches) |
| Overall length: | 1,990 mm (78.3 inches) |
| Overall width: | 850 mm (33.5 inches) |
| Ground clearance: | 310 mm (12.2 inches) |
| Wheelbase: | 1,305 mm (51.4 inches) |
| Fuel capacity: | 2.60 litres (0.69 gallons) |
| Reserve fuel capacity: | 0.50 litres (0.13 gallons) |
| Other specifications |
|---|
| Color options: | Red/black |
